WEICHAI SERIES (22KVA—— 550KVA)
BAUDOUIN SERIES (688KVA—— 4825KVA)
Weichai is a multi-field and multi-industry international group which owns powertrain founded in 1946,,vehicle, construction machinery, intelligent logistics, agricultural machinery, marine transportation equipment and other business sections.Baudouin is a French engine manufacturer founded in 1903.For more than one hundred years, Baudouin has been the primary supplier of military diesel engines for the French military, with comprehensive maritime powertrain system solutions.At the end of 2008 ,It officially became a wholly-owned subsidiary of Weichai Group.At present, Weichai Baudouin products are becoming an important level of Weichai's products.IGNT Power is cooperating with WEICHAI in the field of diesel generator sets to supply diesel generator set with high performance and under global warranty.
| Powered by WEICHAI Series | specification | |||||||
| Genset Model | 50HZ 400/230V | Open Type | Silent Type | |||||
| ESP | PRP | Engine Model | Size(L*W*H) | Size(L*W*H) | ||||
| KVA | KW | KVA | KW | mm | mm | |||
| IG22WP | 22 | 18 | 20 | 16 | WP2.3D25E200 | 1500*750*1050 | 2190*900*1280 | download |
| IG33WP | 33 | 26 | 30 | 24 | WP2.3D33E200 | 1500*750*1050 | 2190*900*1280 | download |
| IG41WP | 41 | 33 | 38 | 30 | WP2.3D40E200 | 1500*750*1050 | 2190*900*1280 | download |
| IG50WP | 50 | 40 | 45 | 36 | WP2.3D48E200 | 1850*800*1100 | 2190*900*1280 | download |
| IG69WP | 69 | 55 | 63 | 50 | WP4.1D66E200 | 1900*870*1180 | 2690*1080*1450 | download |
| IG88WP | 88 | 70 | 80 | 64 | WP4.1D80E200 | 1900*870*1180 | 2690*1080*1450 | download |
| IG103WP | 103 | 83 | 94 | 75 | WP4.1D100E200 | 2050*880*1230 | 2940*1080*1690 | download |
| IG138WP | 138 | 110 | 125 | 100 | WP6D132E200 | 2400*950*1510 | 3290*1130*1850 | download |
| IG165WP | 165 | 132 | 150 | 120 | WP6D152E200 | 2400*950*1510 | 3290*1130*1850 | download |
| IG206WP | 206 | 165 | 188 | 150 | WP10D200E200 | 2850*1040*1580 | 3960*1280*2150 | download |
| IG253WP | 253 | 202 | 230 | 184 | WP10D238E200 | 2850*1040*1580 | 3960*1280*2150 | download |
| IG275WP | 275 | 220 | 250 | 200 | WP10D264E200 | 2850*1050*1620 | 3960*1280*2150 | download |
| IG400WP | 399 | 319 | 363 | 290 | WP12D353E200 | 3350*1150*1800 | 4190*1400*2220 | download |
| IG413WP | 413 | 330 | 375 | 300 | WP13D385E200 | 3350*1150*1800 | 4190*1400*2220 | download |
| IG440WP | 440 | 352 | 400 | 320 | WP13D405E200 | 3350*1150*1800 | 4590*1600*2500 | download |
| IG481WP | 481 | 385 | 438 | 350 | WP13D440E310 | 3350*1150*1800 | 4590*1600*2500 | download |
| IG550WP | 550 | 440 | 500 | 400 | WP13D490E310 | 3350*1150*1800 | 4590*1600*2500 | download |
| Powered by WEICHAI BAUDOUIN Series | specification | |||||||
| Genset Model | 50HZ 400/230V | Open Type | Silent Type | |||||
| ESP | PRP | Engine Model | Size(L*W*H) | Size(L*W*H) | ||||
| KVA | KW | KVA | KW | mm | mm | |||
| IG688WP | 688 | 550 | 625 | 500 | 6M33D633E200 | 3800*1600*2200 | 5282*2100*2500 | download |
| IG756WP | 756 | 605 | 688 | 550 | 6M33D670E200 | 3800*1600*2200 | 5680*2100*2500 | download |
| IG880WP | 880 | 704 | 800 | 640 | 12M26D792E200 | 4000*2000*2250 | 6096*2438*2592 | download |
| IG990WP | 990 | 792 | 900 | 720 | 12M26D902E200 | 4000*2000*2250 | 6096*2438*2592 | download |
| IG1100WP | 1100 | 880 | 1000 | 800 | 12M26D968E200 | 4400*2000*2250 | 6096*2438*2592 | download |
| IG1238WP | 1238 | 990 | 1125 | 900 | 12M33D1108E200 | 4700*2000*2400 | 12192*2438*2591 | download |
| IG1375WP | 1375 | 1100 | 1250 | 1000 | 12M33D1210E200 | 4700*2000*2400 | 12192*2438*2591 | download |
| IG1513WP | 1513 | 1210 | 1375 | 1100 | 12M33D1320E200 | 4700*2000*2400 | 12192*2438*2591 | download |
| IG1650WP | 1650 | 1320 | 1500 | 1200 | 12M33D1500E310 | 4700*2000*2400 | 12192*2438*2591 | download |
| IG1719WP | 1719 | 1375 | 1563 | 1250 | 16M33D1530E310 | 5400*2250*2500 | 12192*2438*2591 | download |
| IG1788WP | 1788 | 1430 | 1625 | 1300 | 16M33D1580E310 | 5400*2250*2500 | 12192*2438*2591 | download |
| IG1925WP | 1925 | 1540 | 1750 | 1400 | 16M33D1680E310 | 5400*2250*2500 | 12192*2438*2591 | download |
| IG2063WP | 2063 | 1650 | 1875 | 1500 | 16M33D1800E310 | 5400*2250*2500 | 12192*2438*2591 | download |
| IG2200WP | 2200 | 1760 | 2000 | 1600 | 16M33D1980E310 | 5400*2250*2500 | 12192*2438*2591 | download |
| IG2200WP | 2200 | 1760 | 2000 | 1600 | 20M33D2020E310 | 5400*2250*2500 | 12192*2438*2591 | download |
| IG2475WP | 2475 | 1980 | 2250 | 1800 | 20M33D2210E310 | 5800*2800*3400 | 12192*2438*2591 | download |
| IG2475WP | 2475 | 1980 | 2250 | 1800 | 12M55D2210E310 | 5800*2800*3400 | 12192*2438*2591 | download |
| IG2750WP | 2750 | 2200 | 2500 | 2000 | 12M55D2450E310 | 6200*2850*3290 | 12192*2438*2591 | download |
| IG3025WP | 3025 | 2420 | 2750 | 2200 | 12M55D2700E310 | 6500*2850*3290 | 12192*2438*2591 | download |
| IG3025WP | 3025 | 2420 | 2750 | 2200 | 16M55D2750E310 | 6500*2850*3290 | 12192*2438*2591 | download |
| IG3300WP | 3300 | 2640 | 3000 | 2400 | 16M55D2900E310 | 6500*2850*3290 | 12192*2438*2591 | download |
| IG3575WP | 3575 | 2860 | 3250 | 2600 | 16M55D3300E310 | 6500*2850*3290 | 12192*2438*2591 | download |
| IG4125WP | 4125 | 3300 | 3750 | 3000 | 16M55D3600E310 | 6500*2850*3290 | 12192*2438*2591 | download |
WEICHAI SERIES (22KVA—— 550KVA) BAUDOUIN SERIES (688KVA—— 4825KVA) Weichai is a multi-field and multi-industry international group which owns powertrain founded in 1946,,vehicle, construction machinery, intelligent logistics, agricultural machinery, marine transportation equipment and other business sections.Baudouin is a French engine manufacturer founded in 1903.For more than one hundred years, Baudouin has been the primary supplier of military diesel engines for the French military, with comprehensive maritime powertrain system solutions.At the end of 2008 ,It officially became a wholly-owned subsidiary of Weichai Group.At present, Weichai Baudouin products are becoming an important level of Weichai's products.IGNT Power is cooperating with WEICHAI in the field of diesel generator sets to supply diesel generator set with high performance and under global warranty.
